Resistors for Impulse Generator,AC test transformer

Wave shaping resistors for LI, SI and LIC of impulse voltage generators;
Wave shaping resistors for impulse current generators;
Charging resistors and protective resistors for AC test systems.
We can do custom made.

Additional Product Information

Applications

Wave shaping resistors for LI, SI and LIC of impulse voltage generators;
Wave shaping resistors for impulse current generators;
Charging resistors and protective resistors for AC test systems.
We can do custom made.

Technical Parameters

Wave Shaping Resistors for Impulse Voltage Generator

Model No Rated Voltage



Rated Resistance
JXDZ-100/75 100kV 75Ω
JXDZ-100/600 100kV 600Ω
JXDZ-100/20K 100kV 20kΩ
JXDZ-150/25 150kV 25Ω
JXDZ-150/105 150kV 105Ω
JXDZ-150/4.5K 150kV 4.5kΩ
JXDZ-200/80 200kV 80Ω
JXDZ-200/300 200kV 300Ω
JXDZ-200/3K 200kV 5kΩ

Charging Resistors for Impulse Voltage Generator

Model No Rated Voltage



Rated Resistance
JCDZ-100/5 100kV 5kΩ
JCDZ-100/10 100kV 10kΩ
JCDZ-150/15 150kV 15kΩ
JCDZ-150/40 150kV 40 kΩ
JCDZ-200/10 200kV 10kΩ
JCDZ-200/20 200kV 20kΩ

Protective Resistors for AC Test System

Model No Rated Voltage Rated Current Rated Resistance
GR100-0.1/3 100kV 0.1A 3kΩ
GR100-0.2/5 100kV 0.2A 5kΩ
GR100-0.5/5 100kV 0.5A 5kΩ
GR200-0.5/3 200kV 0.5A 3kΩ
GR200-1/5 200kV 1A 5kΩ
GR500-0.15/10 500kV 0.15A 10kΩ
GR500-0.5/10 500kV 0.5A 10kΩ
GR500-2/10 500kV 2A 10kΩ
GR1000-0.5/10 1000kV 0.5A 10kΩ



Standards

IEC60060
